Frequency Range:up to 20 MHz
Waveform Types:Sine, Square, Triangle, Ramp, Pulse, Noise, Arbitrary
Amplitude:20 Vpp into 50 Ohms
Resolution:14-bit
Output Impedance:50 Ohms
Memory Depth:16 kpts
Trigger Modes:External, Internal, Manual, Line
The Tektronix 5A48 Arbitrary Waveform Generator is an advanced instrument designed for high-precision applications. Its robust design ensures reliable performance even under demanding conditions. Key features include a wide frequency range up to 50 MHz, allowing users to generate a variety of waveforms with high fidelity. With a sampling rate of 1 GSa/s and 14-bit resolution, this generator provides exceptional accuracy and clarity.
The device supports multiple waveform types including sine, square, triangle, ramp, pulse, and arbitrary waveforms. Users can easily create custom waveforms using the intuitive software interface. Additionally, the built-in functions such as FFT and Bode Plot make it a versatile tool for various testing and analysis tasks.
With a memory depth of 16 kSa, the Tektronix 5A48 allows for extensive data storage and retrieval, ensuring smooth operation during long-duration tests. The generator supports multiple interfaces including USB, LAN, and GPIB, providing flexibility in connecting to different systems.
Designed with user convenience in mind, the Tektronix 5A48 offers easy programmability and control through its user-friendly interface. Its compact design and robust construction make it suitable for both lab bench use and integration into larger systems. The phase shift capability of +/- 1 degree ensures precise control over signal characteristics.
