The SCXI-1126 is an 8-channel, isolated frequency input module for SCXI. Each channel includes a frequency-to-voltage (F/V) converter circuit with programmable input range, threshold, hysteresis, and filtering. The module’s output voltage is multiplexed onto the data acquisition (DAQ) system’s analog input channels for measurement.
The SCXI-1126 is ideal for applications that require high-precision frequency measurements, such as:
- Monitoring rotating machinery
- Measuring fluid flow
- Measuring vibration
- Timing events
The SCXI-1126 is compatible with a wide range of SCXI chassis and DAQ systems. It is also compatible with National Instruments LabVIEW software, which provides a graphical programming environment for data acquisition and analysis.
Here are some of the key features of the SCXI-1126:
- 8 isolated frequency input channels
- Programmable input range: 10 Hz to 10 MHz
- Programmable threshold: 0 to 5 V
- Programmable hysteresis: 0 to 5 V
- Programmable filtering: 1 Hz to 100 kHz
- Output voltage: 0 to 5 V
- ±0.01% accuracy (typical)
- 100 kHz maximum frequency
- Compatible with a wide range of SCXI chassis and DAQ systems
- Compatible with National Instruments LabVIEW software
