The Honeywell TC-IAH161 is a high-level analog input module. It is used to convert analog signals from sensors and other devices into digital signals that can be understood by a computer or other control system.
The TC-IAH161 has the following features:
- 16 single-ended or 8 differential analog inputs
- 16-bit resolution
- +/-10 V, 0 to 5 V, or 4 to 20 mA input range
- Programmable input filters
- Software-selectable excitation voltage for two-wire transmitters
- On-board diagnostics
The TC-IAH161 is typically used in industrial automation applications, such as:
- Monitoring process variables such as temperature, pressure, and flow
- Controlling machinery and equipment
- Data acquisition
Here are some additional details about the TC-IAH161:
- Dimensions: 3.35″ x 5.98″ x 1.02″ (85.1mm x 151.9mm x 25.9mm)
- Weight: 0.45 lbs (0.20 kg)
- Operating temperature: -40 to 70°C (-40 to 158°F)
- Power supply: 24 VDC
Regarding new and used product descriptions:
New product
We guarantee that all new products undergo 100% testing before shipment to ensure normal use.
The new product will be in its original packaging and come with all original accessories.
Second hand products
Some second-hand products may have obvious scratches or other usage marks on the surface.
Second hand products will undergo strict testing before shipment to ensure proper functionality.
Inventory will change periodically, please contact us before purchasing
How long will it take to prepare the product? How long will it take to get the product?
We need 2-3 days to prepare.
