The Honeywell CC-PDIS01 is a Digital Input Sequence of Events (DISOE) module used with the Experion Process Knowledge System (PKS). It is a high-performance module that provides 24VDC discrete inputs with 1ms resolution Sequence of Events (SOE) capability.
Here are some key features of the CC-PDIS01:
- Three modes of operation: Normal (20ms PV scan), Sequence of Events (1ms resolution SOE, 20ms PV scan), and Low Latency (5ms PV scan).
- Extensive internal diagnostics: Helps to ensure data integrity.
- Open Wire Detection: Detects and annunciates open field wires in Normal mode.
- Optional redundancy: Provides increased reliability and availability.
- Internal or external field power selection: Offers flexibility in system configuration.
- On board excitation power: No need for marshalling power.
- Supplies Non-incendive field power: Meets safety requirements for hazardous locations.
- Direct / Reverse Input Indication: Allows for easy identification of input state.
- Galvanic Isolation: Protects the system from electrical noise and interference.
Here are some additional details about the CC-PDIS01:
- Input / Output Model: CC-PDIS01 – Digital Input Sequence of Events
- IOTA Models:
- Non Redundant: CC-TDIL01 (9″)
- Redundant: CC-TDIL11 (12″), CC-GDIL11 (12″), CC-GDIL21 (6″)
- Redundant for exp. 12″: CC-GDIL01
- GI-IS I/O Expander: CC-SDXX01 (12″)
- Input Channels: Varies depending on the IOTA model
- Input Voltage Range: 18 to 30 VDC
- ON Sense Voltage/Current: 13 VDC (min) or 3 mA (min)
- OFF Sense Voltage/Current: 5 VDC (max) or 1.2 mA (max)
