The    GE IS420PPNGH1A   is a Mark VIe series Power Supply Module designed for industrial automation and control systems.

General Specifications:

• Manufacturer: GE (General Electric)
• Series: Mark VIe

• Model: IS420PPNGH1A

• Function: Power Supply Module

Electrical Specifications:

• Input Voltage:
  • Nominal: 24V DC (typical range: 18V–32V DC)
• Output Voltage:
  • +5V DC (for logic circuits)
  • ±15V DC (for analog circuits)
• Output Current:
  • 5V Output: Typically 5A (varies based on load)
  • ±15V Output: Typically 1A (varies based on load)
• Power Rating: ~50W (depends on configuration)
• Efficiency: Typically >85%

Environmental & Mechanical Specifications:

• Operating Temperature Range:
  • -20°C to +70°C (industrial standard)
• Storage Temperature Range:
  • -40°C to +85°C
• Humidity: 5%–95% (non-condensing)
• Cooling Method: Passive/Convection (no fan)
• Enclosure Rating: Typically IP20 (for indoor use)

Compliance & Certifications:

• EMC Compliance: Meets industrial standards (CE, UL, etc.)
• Safety Standards: Complies with IEC 61010-1

Physical Dimensions:

• Length: ~200 mm (varies slightly)
• Width: ~100 mm
• Height: ~50 mm
• Weight: ~0.5 kg

Connector & Interface:

• Input Connector: Terminal block or high-reliability industrial connector
• Output Connector: Backplane or direct wiring

Application:

• Used in GE Mark VIe Speedtronic Turbine Control Systems
• Provides regulated power to I/O modules, controllers, and other system components
