EMERSON KJ3204X1-BA1, 12P3275X032 – DeltaV System Control Module

Product Type:DeltaV System Control Module

Model:KJ3204X1-BA1, 12P3275X032

Module Category:Discrete Output Card

LocalBus Power Rating:+12 VDC at 150 mA

Bussed Field Power Rating:24 VDC at 3.2 A

Terminal Block Key Position:B4

Weight:0.2 kg

Number of Outputs:16

Output Current per Channel:20 mA

Relay Rating:24 VDC @ 2 A

Communication Interface:RS-485

Operating Temperature:-20°C to +55°C

Storage Temperature:-40°C to +70°C

    The Emerson KJ3204X1-BA1 control module is a cornerstone of the DeltaV system, engineered for unparalleled reliability in demanding industrial environments. It seamlessly integrates into the DeltaV platform, offering a robust solution for complex process control scenarios.

    With its high-resolution digital inputs and outputs, this module ensures accurate and responsive control over various process variables. Its compatibility with a wide range of industry standards facilitates seamless integration with existing systems.

    Featuring a compact yet sturdy design, the KJ3204X1-BA1 is optimized for space-constrained installations. It is built to withstand harsh environmental conditions, ensuring consistent performance throughout its service life.

    This module supports up to 32 discrete input signals and can handle up to 32 discrete output signals, making it ideal for applications requiring precise control and monitoring. Its modular architecture allows for easy maintenance and upgrade without disrupting operational continuity.

    Equipped with advanced diagnostic capabilities, the KJ3204X1-BA1 provides real-time feedback on system status, enabling proactive maintenance and minimizing downtime. This feature is particularly valuable in maintaining high operational efficiency and reducing maintenance costs.
