B&R X20DC1376 Incremental Encoder Module In stock

The B&R X20DC1376 is a digital counter module specifically designed to work with incremental encoders within the B&R X20 System. Here’s a breakdown of its key features and functionalities:

Functionality:

• Processes Incremental Encoders: It interfaces with incremental encoders, which provide rotary position information by generating electrical pulses with each shaft rotation.
• 1 ABR Input: Supports encoders with 1 pulse per revolution (ABR).
• 24V Power Supply: Provides 24V DC power to the connected encoder.
• 4x Evaluation: Counts every 4 edges detected on the encoder’s output signals (A and B) for increased resolution.
• Encoder Monitoring: Monitors the health of the connected encoder by checking for signal integrity (A, B, and optional reference pulse R).
• NetTime Function: Enables time stamping of counter changes for precise position tracking within the B&R automation system.

Applications:

The B&R X20DC1376 is suitable for various industrial automation applications requiring precise position or speed control using incremental encoders. Here are some examples:

• Conveyor Belt Systems: Monitors the movement of conveyor belts for precise positioning and control of transported materials.
• Motor Speed Control: Tracks motor shaft rotation for accurate speed control in various industrial machines.
• Robotic Arm Positioning: Provides feedback on the joint positions of a robotic arm for accurate and controlled movement.
• Machine Tooling: Enables precise positioning of cutting tools or machine elements based on encoder readings.
