Bently 3500/33 149986-01
The Bently 3500/33 149986-01 is a 16-channel relay module used in Bently Nevada’s machinery condition monitoring systems. Here’s a breakdown of its key features:
- Function: Provides 16 independent relay outputs for controlling external devices based on pre-programmed logic.
- Installation: A full-height module that can be placed in any slot to the right of the Transient Data Interface (TDI) module in a Bently Nevada rack.
- Programming: Each relay output can be programmed using AND and OR logic based on various inputs like alarm statuses, individual measured variables from monitor channels, etc. This allows for customization of the module’s response to specific machinery conditions.
- Construction: Epoxy-sealed for protection in industrial environments.
Here are some additional details about the relay module:
- Relay Type: Single-pole, double-throw (SPDT)
- Environmental Sealing: Epoxy-sealed
- Relay Contact Life: 10,000 cycles
- Power Consumption: 5.8 watts typical
Bently 3500/33 149986-01 Application Field
1. Oil and Gas
2. Power Generation
3. Chemical Processing
4. Manufacturing
5. Pulp and Paper
6. Turbines
7. Compressors
8. Pumps
9. Fans
Bentley company
Bentley Systems, Incorporated is an American company that develops software for the design, construction, and operation of infrastructure. Their software is used by engineers, architects, constructors, surveyors, and owner-operators around the world.
- MicroStation: A 2D/3D CAD modeling application
- OpenRoads: A software suite for designing and analyzing roads and bridges
- SewerGEMS: A software program for modeling and analyzing sanitary sewer systems
- WaterCAD: A software program for modeling and analyzing water distribution systems
- STAAD.Pro: A software program for structural analysis and design
Bentley main series
| Vibration monitoring module | Monitor module | Power module | Extension cable+probe |
| 3500/05 Framework | 3500/45 Differential Expansion/Axial Position Monitor | 3500/93 System Display Device | 3300XL |
| 3500/15 power module | 3500/46 M Hydroelectric Monitor Module | 3500/95 System Integrated PC Display Device 1900/65A Four Channel Vibration Monitor |
330130 |
| 3500/20 Framework Interface Module | 3500/50 speed module | 1900/15 power module monitor | 330106 |
| 3500/22 M Transient Data Interface Module | 3500/53 Electronic Overspeed Detection System Module | 1900/17 Proximitor Monitor | 330400 |
| 3500/25 Improved Keyphasor Module | 3500/60 Temperature Monitor Module | 1900/25 vibration monitor | 330910… |
| 3500/32 4-Channel Relay Module | 3500/61 Temperature Monitor Module | 1900/27 vibration monitor | |
| 3500/33 16 Channel Relay Module | 3500/62 Process Variable Monitor Module | 1900/55 earthquake monitoring module | |
| 3500/40 displacement monitor | 3500/72 M piston rod position monitoring module | 2300/20 dual channel monitor | |
| 3500/42 M displacement/velocity monitor | 3500/77 M cylinder pressure monitoring module | 2300/25 monitor | |
| 3500/34 TMR Relay Module | 3500/92 Communication Gateway |
