Product Description
The Allen-Bradley 1771-IAN is a 32-point, 120V AC/DC digital input module for the PLC-5 programmable logic controller (PLC) system. It is a modular component of the 1771 I/O system and requires a properly installed system chassis.
Product Parameters
- Number of inputs: 32
- Input voltage range: 85-138V AC, 90-132V DC
- Input current: 10mA per input
- Input impedance: 100kΩ
- Input response time: 10ms
- Operating temperature range: 0-60°C
- Dimensions: 125mm x 80mm x 35mm
Usage Method
To use the 1771-IAN module, it must be installed in a properly equipped PLC-5 system chassis. The module has 32 input terminals, which are arranged in four sets of eight terminals. Each set of eight terminals is connected to a common input terminal.
To wire the module, connect the input devices to the appropriate terminals. For AC inputs, connect the positive terminal of the input device to the terminal marked with a “+” sign and the negative terminal of the input device to the common terminal. For DC inputs, connect the positive terminal of the input device to the terminal marked with a “+” sign and the negative terminal of the input device to the terminal marked with a “-” sign.
Once the module is wired, it must be configured in the PLC-5 PLC program. The module’s address in the PLC program is determined by its position in the system chassis. The module’s input terminals are addressed as I0.0-I31.0, with I0.0 being the address of the first input terminal and I31.0 being the address of the last input terminal.
Product Application
The 1771-IAN module can be used to input a variety of digital signals, such as sensor signals, switch signals, and pushbutton signals. It is commonly used in industrial control applications, such as machine control, process control, and building automation.
Here are some specific examples of how the 1771-IAN module can be used:
- To monitor the status of switches and sensors in a manufacturing machine
- To control the operation of motors and other actuators
- To read the status of input devices in a building automation system, such as temperature sensors, occupancy sensors, and motion detectors
- To interface with other types of control systems, such as CNC machines and robotic controllers
The 1771-IAN module is a versatile and reliable digital input module that can be used in a wide variety of applications.
