Product description:
The ABB UNITROL UN 0056 a-P V .1 is a three-phase VFD with a power rating of 0.55 kW. It has a wide input voltage range of 380-500 V AC and a frequency range of 0.5-500 Hz. The drive is equipped with a number of features, including:
- Programmable acceleration and deceleration times
- Built-in PID controller
- Protection against overvoltage, overcurrent, and short circuit
- Modbus RTU communication protocol
Product parameters:
| Parameter | Value | |—|—|—| | Power rating | 0.55 kW | | Input voltage range | 380-500 V AC | | Frequency range | 0.5-500 Hz | | Output current | 2.3 A | | Output frequency | 0.5-500 Hz | | Protection | Overvoltage, overcurrent, short circuit | | Communication protocol | Modbus RTU |
Usage method:
The ABB UNITROL UN 0056 a-P V .1 is easy to use. It can be programmed using the keypad on the drive or through a PC using the ABB UNITROL UN 0056 a-P V .1 software. The drive is also equipped with a number of features that make it easy to troubleshoot and maintain.
Product application:
The ABB UNITROL UN 0056 a-P V .1 can be used in a wide range of applications, including:
- Industrial automation: The drive can be used to control the speed of motors in a variety of industrial applications, such as conveyors, fans, and pumps.
- HVAC: The drive can be used to control the speed of fans and pumps in HVAC systems.
- Material handling: The drive can be used to control the speed of motors in material handling applications, such as cranes and hoists.
Examples:
- The ABB UNITROL UN 0056 a-P V .1 can be used to control the speed of a fan in an HVAC system. This can help to reduce energy consumption and improve the comfort of the building.
- The ABB UNITROL UN 0056 a-P V .1 can be used to control the speed of a conveyor in a factory. This can help to improve the efficiency of the production process.
- The ABB UNITROL UN 0056 a-P V .1 can be used to control the speed of a crane in a warehouse. This can help to improve the safety and efficiency of the material handling process.
UNITROL® Excitation Systems
Excitation systems are a key component in many power generating units used by plant owners and operators to achieve reliability of operations, stability and fast transient response of their assets, as per grid requirements.
UNITROL® 1000 Series
The UNITROL® 1000 Series is ABB’s brushless excitation system for applications using synchronous machines ranging from 100kVA to 80MVA.
UNITROL® 1020
UNITROL 1020 is the voltage regulator intended for small and medium synchronous generators and industrial machines. It combines performance control and power circuits with a simple mechanical design provides high performance in a wide range of temperature and vibration conditions .
With built-in dual channel support, advanced load sharing between machines operating in parallel, rotating diode monitoring, automatic synchronizing and several integrated communication options, this automatic voltage regulator (AVR) is manufactured using the most advanced microprocessor technology and IGBT semiconductors allowing current output up to 20 ADC for continuous operation.
UNITROL® 1010
UNITROL® 1010 is the Indirect Excitation System for small and medium synchronous generators and industrial machines. Its advanced microprocessor technology and IGBT semiconductors allow for current output up to 10 ADC for continuous operation.
With built-in dual channel support, advanced load sharing between machines operating in parallel, rotating diode monitoring, automatic synchronizing and several integrated communication options, UNITROL 1010 provides high performance in a wide range of temperature and vibration conditions.
UNITROL® 1005
UNITROL 1005 is the smaller component of the family designed for low-end excitation application with maximum excitation current up to 5 ADC.
Like all UNITROL1000 products, UNITROL 1005 is based on the same target software source code and share the same simulation models that makes it very suitable for demanding grid code applications.
Included in the package is CMT1000, the tool for focused and fast commissioning.
UNITROL® 1000 Flex Systems
UNITROL® 1000 FLEX Systems are prepackaged solutions for applications requiring single or dual channel controllers. All systems are fitted with UNITROL® 1020 FULL as a standard device, leveraging the best solution for optimum price and flexible project adjustment constraints.
