Product Description

ABB PP825 is a touch screen panel for ABB AC 800M DCS. It is a 12-inch color TFT display with a resolution of 800×600 pixels. The PP825 has a resistive touch screen that can be operated with a finger or stylus. It is also equipped with a number of buttons, including a navigation keypad, function keys, and a power button.

Product Parameters

• Display size: 12 inches
• Display type: Color TFT
• Display resolution: 800×600 pixels
• Touch screen type: Resistive
• Operating temperature: 0 to 55 degrees Celsius
• Storage temperature: -20 to 70 degrees Celsius
• Dimensions: 368mm x 289mm x 92mm
• Weight: 6.3kg

Usage Method

The PP825 is used to interact with the ABB AC 800M DCS. It can be used to view and monitor process data, enter commands, and configure the DCS. The PP825 is also used to troubleshoot problems with the DCS.

To use the PP825, first connect it to the AC 800M DCS using the Ethernet cable provided. Then, power on the PP825. The PP825 will automatically connect to the DCS and start displaying the process data.

To navigate through the PP825 menus, use the navigation keypad on the left side of the screen. To select an item, press the enter key. To enter a command, use the function keys on the right side of the screen.

To configure the PP825, press the menu key on the left side of the screen. This will open the PP825 configuration menu. Use the navigation keypad to select the item you want to configure and then press the enter key.

Product Application

The PP825 is used in a variety of industrial applications, including:

• Oil and gas
• Power generation
• Food and beverage
• Chemical processing
• Pharmaceutical manufacturing
• Metals and mining
• Water and wastewater treatment

Example

In a power generation plant, the PP825 could be used to monitor the following process data:

• Turbine speed
• Generator output
• Boiler pressure
• Steam temperature
• Feedwater flow

The PP825 could also be used to enter commands to the DCS, such as:

• Start the turbine
• Stop the turbine
• Increase the generator output
• Reduce the generator output

The PP825 could also be used to troubleshoot problems with the DCS, such as:

• Identifying a faulty sensor
• Isolating a network problem
• Configuring the DCS to recover from a fault

The ABB PP825 is a versatile and powerful touch screen panel that can be used in a wide variety of industrial applications.
